Specifications

Sizes / ThicknessesCollins Pine UniForm 48#Collins Pine UniForm 50#
Press Size5’ x 24’5’ x 24’
Thickness (Inches)*7/16″ – 3/4″7/16″ – 3/4″
Thickness Tolerance**±.003” avg thickness from target range**±.003” avg thickness from target range**
Length/Width Tolerances±1/16”±1/16”
Squareness Tolerance±1/32” per foot of panel width±1/32” per foot of panel width

*Metric sizes within range also available
**Based on 3/4”

Physical Properties*48#50#
Density48 lbs/cu ft50 lbs/cu ft
Internal Bond160 psi180 psi
Modulus of Rupture2600 psi3250 psi
Modulus of Elasticity425,000 psi550,000 psi
Screw Holding – Face350 lbs375 lbs
Screw Holding – Edge250 lbs300 lbs

Physical properties tested using method ASTM D 1037-06a. Complies with ANSI A208.1-2022.
Our NAF resin enables our products to be third-party certified CARB Exempt TSCA Title VI.

Collins Industrial Pine Particleboard location, wood product manufacturing

ORIGIN

Klamath Falls, Oregon

PARTICLEBOARD OPTIONS

  • Commercial
  • Industrial
  • Industrial 2
  • Industrial 3
  • MR10
  • MR50
  • Collins Pine FreeForm®
