Specifications

Sizes / ThicknessesIndustrial 3 Specs
Press Size5’ x 24’
Thickness (Inches)*3/8” – 1-3/16”
Thickness Tolerance**±.003” avg thickness from target range**
Length/Width Tolerances±1/16”
Squareness Tolerance±1/32” per foot of panel width

*Metric sizes within range also available
**Based on 3/4”

  • Physical Properties*
  • Density
  • Internal Bond
  • Modulus of Rupture
  • Modulus of Elasticity
  • Screw Holding – Face
  • Screw Holding – Edge
  • Commercial Specs
  • 42 lbs/cu ft
  • 60 psi
  • 1,310 psi
  • 257,000 psi
  • 171 lbs
  • 108 lbs
  • Industrial Specs
  • 45 lbs/cu ft
  • 80 psi
  • 1,700 psi
  • 298,000 psi
  • 205 lbs
  • 155 lbs
  • IND 2
  • 46 lbs/cu ft
  • 90 psi
  • 1,885 psi
  • 290,100 psi
  • 225 lbs
  • 180 lbs
  • IND 3
  • 47 lbs/cu ft
  • 100 psi
  • 2,176 psi
  • 362,600 psi
  • 225 lbs
  • 202 lbs
  • MR10
  • 46 lbs/cu ft
  • 90 psi
  • 1,885 psi
  • 290,100 psi
  • 225 lbs
  • 180 lbs
  • MR50
  • 49 lbs/cu ft
  • 150 psi
  • 2,500 psi
  • 410,000 psi
  • 300 lbs
  • 240 lbs

*Physical properties tested using method ASTM D 1037-06a. Complies with ANSI A208.1-2022.

Collins Industrial Pine Particleboard location, wood product manufacturing

ORIGIN

Klamath Falls, Oregon

PARTICLEBOARD OPTIONS

  • Commercial
  • Industrial
  • Industrial 2
  • MR10
  • MR50
  • Collins Pine FreeForm®
  • Collins Pine UniForm™
